Τα JL Audio M6-10IB-C-GWGW-4 ειναι subwoofer θαλασσης 10" (για σκαφη, πισινες). Αντοχη 250 wrms και τοποθετειται σε  κλειστο κουτι. Γριλλια White Classic.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων.

Specifications

• Size 10"
• Color White Classic
• Physical dimensions Diameter 273 mm
• Physical dimensions Depth 192 mm
• Speaker type Infinite Baffle Subwoofer
• Continuous power handling (RMS) 250 W
• Sensitivity (SPL @ 1 W/1 m) 86.4 dB
• Nominal impedance 4 Ω
• Recommended amplifier power (RMS) 75-250 W
• Cone material Injection-molded, mica-filled polypropylene
• Warranty 3 years
• Speaker connections Spade Connectors
• Mounting diameter clearance 150mm
• Frontal grille protrusion 42 mm
• Mounting depth clearance 127 mm
• Mounting hole 225 mm
• Bolt hole circle 247 mm

Woofer Parameters

• Free Air Resonance (FS) 34.58 Hz
• Electrical “Q” (Qes) 0.522
• Mechanical “Q” (Qms) 9.780
• Total “Q” (Qts)    0.496
• Equivalent Compliance (Vas) 1.22 cu ft (34.49 L)
• One-way linear excursion (Xmax; specs are derived via one-way voice coil overhang method with no correction factors applied)  0.52" (13 mm)
• Reference Efficiency (NO) 0.28%
• Effective piston area (SD) 50.11 in² (0.0323 m²)
• DC resistance (RE) 3.619 Ω

Seakerd Enclosure Specifications

• Wall thickness    19 mm
• Front baffle thickness    19 mm
• Volume (net int.) 56.6 L
• 10" (W): 21.2 L
• External width (W) 432 mm
• External height (H) 432 mm
• External depth (D) 184 mm
• -3 dB cutoff frequency (F3) 41.54 Hz
• 10" (W): 50.08 Hz
• System resonance (FC) 56.01 Hz
• System Q at resonance (QTC) 0.8035
