Ο Arcam AVA15 ειναι ενας ενισχυτης home cinema, 9 καναλιων ισχυος class-D, 7x85 watts/8Ω και διαχειρισης εως 12 καναλιων μεσω preouts.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων.

With nine channels of amplification, the AVA15 drives setups like 7.1.2 or 5.1.4 with ease—and gives you room to expand with extra subwoofers, height, or surround speakers. Dolby Atmos and DTS:X bring cinema-grade immersion to your home, while Dirac Live room correction ensures every detail sounds perfect in your space.

Features

• Class D Amplification with 9x 85W Power Output into 8Ω (20Hz – 20kHz, 0.5% THD, 2 channels driven)
• Dolby Atmos - Bring even the smallest details to life with sound that moves in all directions.
• DTS:X - place sound where it would occur naturally in space, creating the most lifelike, multi-dimensional audio experience ever.
• Dirac Live Room Correction for exceptional, calibrated audio in any room - upgrade with Dirac Live Bass Control and Dirac Live Active Room Treatment
• Bluetooth remote control for continuous out-of-sight control
• Works with the new ARCAM Radia app for setup, control, Internet Radio, Podcasts and UPnP playback from iOS, Android and Windows devices and PCs
• Supports Apple Airplay, Google Cast, Spotify Connect, Tidal Connect and Qobuz Connect
• Works with Apple and Android devices, with direct connection from lossless music services
• Bluetooth with Snapdragon Sound and Auracast for the best wireless sound with the most convenience
• Large High-resolution display for clearly visible status and metadata from the comfort of your main listening position
• Plastic free packaging for easy disposal of natural materials

Specifications

• Decoding & Processing:
  • Maximum Processing Channels: 12
  • Reassignable Channels: Front, Surround Back, Height
  • Dolby Atmos
  • Dolby TrueHD
  • Dolby Atmos Height Virtualisation
  • Dolby Surround
  • DTS:X
  • DTS-HD Master Audio
  • DTS Neural:X
  • DTS Virtual:X
  • MPEG-H
• HDMI:
  • Inputs / Outputs: 7 / 2
  • HDMI / HDCP: 2.1a / 2.3
  • Maximum Resolution: 8K/60Hz or 4K/120Hz
  • HDR, HDR10, HDR10+, HDR10+ Gaming, Dolby Vision, HLG
  • Variable Refresh Rate (VRR)
  • Auto Low Latency Mode (ALLM)
  • CEC
  • eARC / ARC via HDMI Output 1
  • On-Screen Display
• Streaming & Network Audio:
  • ARCAM Radia AV Control
  • Spotify Connect
  • TIDAL Connect
  • Qobuz Connect
  • Roon Ready
  • Apple AirPlay
  • Google Cast
  • Internet Radio
  • Podcasts
  • UPnP
  • Supported Formats: FLAC, WAV (LPCM), AAC, ALAC, AIFF, MP3, OGG
  • Gapless Playback
  • Bit Depth: 16-bit / 24-bit
  • Sample Rate: up to 192kHz
  • Frequency Response: 20Hz – 20kHz ±0.05dB
• Digital Inputs:
  • 2 x Coaxial RCA
  • 2 x Optical Toslink
  • Coaxial Sample Rates: 44.1, 48, 88.2, 96, 176.4, 192kHz
  • Optical Sample Rates: 44.1, 48, 88.2, 96kHz
  • Bit Depth: 16-bit / 24-bit
  • Frequency Response: 20Hz – 20kHz ±0.2dB
  • Signal-to-Noise Ratio: 100dB (A-weighted, ref. 50W, 0dBFS)
• Analogue Inputs:
  • 3 x Stereo RCA
  • Signal-to-Noise Ratio: 100dB (A-weighted, ref. 50W, 1V input)
  • Frequency Response: 20Hz – 20kHz ±0.2dB
• Preamplifier Outputs:
  • 12 x RCA
  • Maximum Output Level: 2Vrms per channel
  • THD+N: -100dB (20Hz – 20kHz)
• Amplification:
  • 9-channel Class D amplification
  • 85W per channel into 8Ω (20Hz – 20kHz, 0.5% THD, 2 channels driven)
  • 150W per channel into 4Ω (1kHz, 0.5% THD, 2 channels driven)
  • 85W per channel into 8Ω (20Hz – 20kHz, 0.5% THD, 7 channels driven)
  • 65W per channel into 4Ω (1kHz, 0.5% THD, 7 channels driven)
  • Harmonic Distortion: 0.003% (80% power, 8Ω, 1kHz)
• Wireless Connectivity:
  • Bluetooth 5.4
  • Bluetooth Profiles: A2DP Sink/Source, AVRCP, Snapdragon Sound, AAC, LE Audio, Auracast, GATT, VCP, MCP, BAP, CAP
  • Bluetooth Frequency Range: 2402–2480MHz
  • Bluetooth Transmit Power: <10.73dBm
  • Wi-Fi: IEEE 802.11 a/b/g/n/ac, 2.4GHz / 5GHz
  • 2.4GHz Wi-Fi Frequency Range: 2.400–2.4835GHz
  • 2.4GHz Wi-Fi Transmit Power: <17.4dBm
  • 5GHz Wi-Fi Frequency Range: 5.15–5.35GHz / 5.47–5.725GHz / 5.725–5.875GHz
  • 5GHz Wi-Fi Transmit Power: <19.26dBm
• Power:
  • Mains Supply: 100–120V or 220–240V AC, 50/60Hz
  • Maximum Power Consumption: 900W
  • Idle Power Consumption: 59W
  • Standby Power Consumption: 2W / 0.3W (Default / Low Power)
  • Maximum Thermal Dissipation: 3070 BTU/hour
  • Idle Thermal Dissipation: 200 BTU/hour
• Dimensions: 432 x 407.4 x 170 mm, W x D x H
• Net Weight: 10kg
• Packed Weight: 15.7kg
• Supplied Accessories:
  • Region-specific power cord(s)
  • Rear panel cowl
  • Remote control with 2 x AAA batteries
  • Measurement microphone
  • 5m USB cable
  • Quick Start Guide
  • Important Safety Instructions
