Ο Lyngdorf MP-60 2.1 ειναι AV processor 16 καναλιων. Αποκωδικοποιει Dolby Atmos, DTS-X, και Auro-3D. Διαχειριζεται σηματα εικονας 8K/60Hz.

Εγγύηση Αντιπροσωπείας. Δυνατότητα δόσεων.

State-of-the-art HDMI processing
The MP-60 2.1 processor is intuitive to use and offers extraordinarily easy installation. It decodes up to 16 native audio channels which can be mapped out intelligently through the sleek website interface. The MP-60 2.1 offers full support of the latest immersive surround formats including Dolby Atmos®, DTS:X® Pro and AURO-3D®.

With five HDMI inputs and two outputs, this new masterpiece from Lyngdorf Audio now supports HDMI 2.1 including features eARC, Dynamic Lip-Sync and QMS (Quick Media Switching) as well as the latest decoding and post-processing formats. The MP-60 2.1 supports 40 Gbps fixed rate link (FRL) and 18 Gbps transition minimized differential signaling (TMDS) video rates. The MP-60 2.1 supports Variable refresh rate (VRR), Quick Frame Transport (or Fast Vactive), and auto low latency mode (ALLM) support and high dynamic range (HDR) metadata passthrough for HDMI dynamic HDR, HDR10+, and Dolby Vision™.

eARC will allow for a full Dolby Atmos audio bitstream being returned to the processor from the television, ensuring full audio quality from the TV’s built-in media players.

Specifications

• Decoding:
  • 16 decoding/upmixing channels
  • Dolby Atmos®
  • DTS:X Pro, 14 channels
  • AURO-3D®, 14 channels
  • All legacy codecs
• Post Processing Options:
  • Dolby Surround
  • AURO-MATIC®
  • DTS Neural:X
• Audio Inputs:
  • 5 x HDMI inputs, including 1 x HDMI eARC, up to 192kHz / 24-bit
  • 1 x AES/EBU S/P-DIF input, up to 192kHz / 24-bit
  • 3 x S/P-DIF coaxial inputs, up to 192kHz / 24-bit
  • 4 x S/P-DIF optical inputs, up to 96kHz / 24-bit
  • 1 x USB audio input, up to 192kHz / 32-bit
  • 1 x microphone input, XLR, for RoomPerfect™
• Audio Outputs:
  • 16 x XLR analog outputs, 8 Vrms max.
  • 1 x S/P-DIF coaxial digital ZONE output, fixed 96kHz / 24-bit
• Audio Specifications:
  • Frequency response: ±0.5dB from 20Hz to 20,000Hz
  • Total harmonic distortion: 0.005% max from 20Hz to 20,000Hz
• EQ:
  • RoomPerfect™
  • Subwoofer level assistant
  • 32 x adjustable voicings, each holding up to 8 shelving, high-pass, low-pass or parametric filters with adjustable gain and Q
• Media Player:
  • Internet radio: vTuner, airable
  • AirPlay 2
  • Spotify Connect
  • Tidal Connect with Dolby Atmos Music
  • Roon Ready
  • DLNA support
  • Support of FAT32-based media storage, uPnP / see DLNA formats
• Video Inputs:
  • 5 x HDMI 2.1 inputs, HDCP 2.3
  • Accepts 8K/30 RGB / YCbCr 4:4:4 10-bit video
  • Accepts 8K/60 YCbCr 4:2:0 10-bit high-definition video
  • Accepts 4K/120 4:4:4 10-bit high-frame-rate video
  • Variable Refresh Rate, VRR
  • Fast Vactive, FVA
  • Auto Low Latency Mode, ALLM
  • HDR, Dolby Vision™ and HLG support
• Video Outputs: 2 x HDMI outputs, HDCP 2.3
• Control Interfaces:
  • 1 x DB9 RS232 connector
  • 2 x IR sensor inputs
  • 1 x IR output, loop from one of the sensor inputs
  • 1 x trigger input
  • 4 x trigger outputs
  • 1 x RJ45 Ethernet LAN connector
  • 2 x USB-A connectors
  • 1 x SD card slot, backup storage for system software and settings
• Accessories Included:
  • RoomPerfect™ microphone
  • Microphone stand
  • Microphone cable
  • RF remote control
• Optional Modules:
  • 16-channel DCI-compliant digital AES/EBU input for movie servers, supports up to 32-bit / 192kHz
  • 16-channel digital AES/EBU output module, fixed 24-bit, selectable 48kHz or 96kHz
  • 16-channel AES67 digital input/output module, supports up to 32-bit / 192kHz input, output fixed at 24-bit / 48kHz
• Remote Control: Infrared / RF
• Standby Power Consumption: < 0.5W
• Heat Dissipation Value: 340 BTU
• Placement Options:
  • Rack mount, 4RU
  • Freestanding
• Dimensions: 14.7 x 45.0 x 37.0 cm, H x W x D
• Weight: 9 kg
