Τα Paradigm Premier-520LCR v2 ειναι κεντρικο ηχειο home cinema 3 δρομων, με 2x 6" Carbon-X woofers, 1x 5.5" AL-MAG midrange και 1x 1" ceramic dome tweeter. Ευαισθησια 93 db.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων.

The 520LCR v2 is a dedicated Left/ Center/Right solution designed for high-performance theater. Its acoustic suspension (sealed) design allows for flexible placement in cabinets o freestanding without compromising clarity. A Coaxial AL-MAG™ midrange ensures clear dialogue and precise imaging, creating a seamless front stage with balanced, natural sound.

Specifications

• Design: 4-driver, 3-way sealed LCR speaker with AL-MAC™, AL-MAG™, Carbon-X™, OSW™ and PPA™ technologies
• Crossover:
  • 2nd order electro-acoustic at 1.5 kHz (tweeter / midrange)
  • 2nd order electro-acoustic at 650 Hz (midrange / woofer)
• High-Frequency Driver:
  • 1” (25 mm) AL-MAC™ ceramic dome tweeter
  • Oblate Spheroid Waveguide (OSW™)
  • Perforated Phase-Aligning (PPA™) tweeter lens
  • Ferro-fluid damped / cooled
• Midrange Driver:
  • Coaxial 6” (152 mm) AL-MAG™ cone
  • 2” high-temp multi-layered voice coil with Apical™ former
  • Patented Dual-Sync™ continuous flux motor
• Bass Drivers:
  • Two 6” (152 mm) ultra-high-excursion CARBON-X™ unibody woofers
  • Gen3 Active Ridge Technology (ART™)
  • Vertical mounting system
  • 1” high-temp multi-layered voice coils with ventilated Apical™ formers
• Frequency Response On-Axis: ±3 dB from 75 Hz – 23 kHz
• Frequency Response 30° Off-Axis: ±3 dB from 75 Hz – 20 kHz
• Low Frequency Extension: 50 Hz (DIN)
• Sensitivity: 93 dB (room) / 90 dB (anechoic)
• Suitable Amplifier Power Range: 15 – 120 Watts
• Maximum Input Power: 80 Watts
• Impedance: Compatible with 8 ohms
• Weight: 14.1 kg each
• Dimensions (H × W × D): 21.1 × 59.4 × 30.5 cm
• Finishes: Piano Black, Black Walnut, Walnut, Satin White
