O Roksan Caspian 4G Power Amplifier ειναι ενας τελικος ενισχυτης 2x85 wrms στα 8ohms.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων, ανταλλαγων.

The Caspian 4G Power Amplifier is engineered to deliver uncompromising drive and power, whether used in stereo or mono-block configuration. It harnesses Roksan’s advanced Euphoria amplification architecture and precision-engineered analogue circuitry to ensure a transparent signal path that preserves every detail and dynamic nuance of the music. When paired with the Caspian 4G Streaming Pre-Amplifier, it forms a performance-focused duo. With fully balanced signal paths, together they unlock extraordinary clarity, authority and scale across all genres.

Features

• Euphoria Amplification
• RCA and XL Inputs
• MaestroUnite Setup & Control App
• 105 Watts into 8 Ohms
• 200 Watts into 4 Ohms
• 420W into 8 Ohms
• 630W into 4 Ohms Mono-bridged

Specifications

• Connectivity Summary
  • Analogue Inputs
    • 2 × RCA Stereo (A1, A2)
    • 1 × Balanced XLR (A3)
  • Digital Inputs: -
  • Analogue Outputs
    • 2 × RCA Stereo (Line 1, Line 2)
  • Amplifier Output: 1 × Pair of speaker binding posts (L & R)
  • Other Inputs / Outputs
    • Wi-Fi 4
    • Bluetooth LE
    • 12V Trigger
    • Wired IR
  • Power: IEC C14, Fused 6.3AT – 250V
• User Interface
  • Primary Interface (on unit): Power button (On/Standby)
  • Secondary Interface (on unit): --
  • Remote Control: MaestroUnite App
• Power Amplifier Section
  • Power Amplifier Technology: Dual Mono Euphoria Amplifier (Mono-Bridge Capable)
  • Amplifier Class: AB
  • Output Power, 8 Ω (235 VAC @ 1% THD, both channels driven): 105 W
  • Output Power, 4 Ω (235 VAC @ 1% THD, both channels driven): 200 W
  • THD+N (1 W @ 1 kHz, both channels driven): <0.007%
  • Gain: 29 dB
  • Signal to Noise (1 W/8 Ω, 2 Vrms A1, both channels driven) – Stereo: >85 dB
  • Output Power, 8 Ω (235 VAC @ 1% THD) – Mono-Bridged: 420 W
  • Output Power, 4 Ω (235 VAC @ 1% THD) – Mono-Bridged: 630 W
  • Frequency Linearity (20 Hz – 20 kHz): ±0.25 dB
  • Power Supply: 600 VA / 36,400 μF per rail
• Analogue Inputs
  • Maximum Input Level
    • 1.1 Vrms RCA, 2.2 Vrms XLR – Stereo
    • 2.2 Vrms RCA, 4.2 Vrms XLR – Mono
  • Music Sense: A2 input
  • AV Mode: -
• MaestroUnite & Power
  • MaestroUnite Supported: Yes
  • Network Connectivity: Bluetooth LE; Wi-Fi 4 (only connects for over-the-air updates)
  • Wired IR Input: 5 – 14 V, mono 3.5 mm jack, any polarity
  • 12V Trigger Input: 5 – 14 V, 3.5 mm jack dual polarity (On/Standby)
  • 12V Trigger Pass-through: 3.5 mm jack, pass-through from input only
  • Nominal Mains Voltage: Auto-selecting power supply, 100–120 VAC & 220–240 VAC
  • Power Consumption: 610 VA; Standby 0.5 W; Network standby 2 W (Standby Plus)
• Mechanical
  • Available Finishes
    • Silver
    • Black
  • Construction: Extruded and machined aluminium front & top cover with extruded aluminium heatsinks
  • External Dimensions with all accessories fitted (H × W × D): 93 × 432 × 378 mm
  • Weight (Product, each): 14.9 kg
  • Sold As: Single
