Το Keces P9 ειναι γραμμικο τροφοδοτικο DC (και φιλτρο) που παρεχει σε 2 ζωνες συνεχους ρευματος (DC), Α ζωνη: 5V, 7V, 9V και 12V, Β ζωνη: 12V, 15V, 19V, 24V, στα 5Α amperes, για switchers, routers, optical isolators κλπ.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων.

Features

• Transformer: In-house developed toroidal transformer with precision winding and low-noise performance
• Grounding: Independent ground per output rail for reduced cross-interference
• Circuit Design: Fully discrete architecture (no ICs), optimized for natural and refined sonic performance
• Noise Performance: Ultra-low ripple noise for clean and transparent signal delivery
• Outputs
  • Dual output configuration
  • 4A and 5A outputs (peak up to 7A)
• DC Output Interface: Gold-plated DC jack for low resistance and improved conductivity
• AC Input Stage
  • OCC silver internal wiring
  • 2 oz copper PCB
• Ground Terminal: Dedicated grounding point for reduced system noise and improved soundstage
• Acoustic Noise: Silent operation with no hum or buzz at 50 Hz and under peak load
• Protection: Over Temperature Protection (OTP)

Specifications

• Output Voltage & Current
  • Zone I: 5V / 7V / 9V / 12V, 4A (peak 5A)
  • Zone II: 12V / 15V / 19V / 24V, 5A (peak 7A)
• Ripple Noise
  • < 220 µV (full power)
  • < 150 µV (at 60 W)
• Power Requirement: Max 330 W
• Casing: Full aluminum chassis
• Dimensions (W × D × H): 300 × 220 × 66 mm
• Weight
  • Net: 6 kg
  • Shipping: 7 kg
